Adjusting Size American Door Closer , Heavy Duty Regular Arm Door Closer

Name: Adjusting Size American Door Closer Heavy Duty Regular Arm Door Closer
Brand: Dorrenhaus, DORHAUS
Price: 17.00 USD

Buy cheap Adjusting Size American Door Closer , Heavy Duty Regular Arm Door Closer product

Brand Name : Dorrenhaus, DORHAUS

Model Number : D4016

Certification : ANSI/BHMA A156.4 Grade 1, UL 228

Place of Origin : Zhejiang, China

MOQ : 100 pcs

Price : USD17.00 - USD18.00 per pc

Payment Terms : L/C, D/A, D/P, T/T, Western Union

Supply Ability : 20,000 pcs per month

Delivery Time : 5 weeks

Packaging Details : 1 pc in 1 paper box, 10pcs in carton of 563*343*190mm, 30ctns in 1 wooden pallet size: 115*106cm

Main Keyword : American Door Closer

Optional : Hold Open

Closing Power : 1 - 6

Warranty : 3 years

Door Width : 850-1500mm

Weight Suitable : 20-150kgs

Opening Angle : 180 degree

Temperature Range : -40℃ to 45 ℃

Contact Now

Adjusting Size American Door Closer , Heavy Duty Regular Arm Door Closer

Exquisite Craft: smooth running, no oil leakage, noiseless
ANSI 156.4 Grade 1 certification, 2 millions life cycles
UL listed and cUL listed for doors without hold open

Dorrenhaus’ most popular medium heavy duty door closer, designed for high
traffic applications. .

Precised cast aluminum cylinder with screw thread steel swing arm
Hydraulic structure, Needle bearing, twice heat treated rack and pinion
Latching & closing speed adjustable by two separate regulating screws
Designed for ADA compliant, adjusting closing force size 1 to 6
Applicable door width: 85cm - 150cm, door weight: 25 - 150kg
Commercial usage for parallel arm, top jamb and regular arm mounted
Non-sized, delayed action and accessibility options
Meet UL 10C standard, investigated up to 3 hours fire resistant
Long-term cooperative supplier of world's top door hardware brands

Finishes - Painted: Aluminum, Bronze, Black, White, Gold, Brown

* MEET YOUR REQUIREMENTS: surface mounted design and full set of screw, allow
you to install this over any high-traffic area, while providing complete control
* ADJUSTING ACCORDING TO YOUR REQUEST: let customer act at their own pace.
You get 6 levels of closing power to suit any level of traffic
* CERTIFIABLY TRUSTABLE: ANSI 156.4 - Grade 1 is the top standard which can be
achieved by door closers. This model is actually super passed 2 million+ cycles testing.
* SPRING FORWARD, EASY CLOSING: commercial-level swing arm won’t interfere with
opening, while closing doors slowly enough to allow graceful entrance and exit
* SOFT, NO NEED TO CLOSE MANUALLY: allow the door do the work, enjoy self-acting
closing and locking, keep quiet and safety.

Type No.	Max. Door Width	Max. Door Weight	Body Size (LxWxH)	Mounting Dim.
D4016	800-1500 mm	20-150kg	24644.569.5mm	230*19mm
Open Angle Range	Quality Assurance	Average Life Cycles	Fire Rating Standard	Certification
180º	3 years	3,000,000	UL 10C - 3H	ANSI 156.4 - Grade 1

Adjusting Size American Door Closer , Heavy Duty Regular Arm Door Closer
